BZ001M056A ADT‐DK300A/400A Engraving Machine

125
Effectivetime : Instant
Note : ThereferencepositionontheZ‐axisdirectioninstraighttoolmagazine;
ifthestraighttoolismountedontheZ‐axisdirection,thispar amet ercan
beused,typicallythepositionofthefirsttool,othertoolsarecalculated
withrespecttothereference
toolpositionandinterval.
006  ATCsafetyheight(mm)
Range :‐9999~9999
Unit : Mm
Authority : Operationadminorhigher
Default : 0.000
Effectivetime : Instant
Note : Safe height of tool change, which should consider the longest tool
holder in the tool magazine before setting this parameter. Make sure
thatthereisnopositioninterference.
007  ATChighspeed(mm/min)
Range :‐9999~9999
Unit : Mm
Authority : Operationadminorhigher
Default : 0.000
Effectivetime : Instant
Note : The speed that each axis quickly locates the set position when tool is
changed.Forexample,ifsafeheightislocated,thesafepositionusethis
speed.
008  ATClowspeed(mm/min)
Range :‐9999~9999
Unit : Mm
Authority : Operationadminorhigher
Default : 0.000
Effectivetime : Instant
Note : The speed that each axis slowly locates the set position when tool is
changed.Thisparameterisusedwhentakingandplacingthetool.
009  Quickdeclineposition(mm)
Range :‐9999~9999
Unit : Mm
Authority : Operationadminorhigher
Default : 0.000
Effectivetime : Instant
Note : This parameter is reserved. Current straight tool doesn’t use this
parameter. You can use this parameter in customized tool magazine
macroprogram.
010  Toolplacingposition(mm)
Range :‐9999~9999
