Theoperat ionfollows:
Enter[Position]interface;Switchto[Relative]interface;Then,entermanualmode;PressacoordinateaxisNo.,e.g.,‘X’,and
theXcoordinateflashes;Press“Cancel”toresetXcoordinateto0;
Therelativepositioninterfacefollows:

RelativePositionInterface
8.1.3.  Comprehensivecoordinates
Theinterfacedisplayedbyabsolutecoordinatesandmachinetoolcoordinates.
Comprehensivepositioninterfaceisshownbelow:
