BZ001M056A ADT‐DK300A/400A Engraving Machine

144
ACcontactor
B

ACcoil(24VDC)
BundlethecablesofgroupBseparatelyfromgroupAorshieldgroup
B;groupBandgroupCshouldbeasfaraspossible
DCrelay(24VDC)
Cablebetweensystemand
strongcurrentcabinet
Cablebetweensystemand
machinetool
C
Cablebetweensystemand
servodrive
BundlethecablesofgroupCseparatelyfromgroupA,orshieldgroup
C;keepatleast10cmclearancebetweengroupCandgroupBanduse
twistedpair
Positionfeedbackcable
Positionencodercable
Handwheelcable
Othercablesforshielding
11.2. Interfacedefinition
11.2.1. Motordrivecontrolinterface(XS1…XS4)
Fourdriveinterfacesareavailable(XS1Xaxis,XS2Yaxis,XS3Zaxis,XS4Aaxis),andtheyhavethesame
definition,asshownbelow:

Pulsewireconnection
