BZ001M056A ADT‐DK300A/400A Engraving Machine

43

Systeminfointerfaceisshownbelow:

SystemInfoInterface
8.5. MDIinterface
MDImodeismainlyusedfortheexecutionofsingleGcodeincertainoccasions.
ToenterMDIinterface:

InMDIinterface,entercompleteNCcodeinstructionineditmode,pressthe[Start]keyintheeditmode
andconfirmtoexecutedirectly.
Torestore the defaultsettingsquickly,press
andholdthe[Reset]keyforthreesecondsand  chooseto
resetornot.
MDIinteractioninterfaceisshownbelow:
[Monitor]
[MDI]
0.6.09
12‐07‐0917:12:18
1.7
108
34
13
