IOConfigurationParametersInterface
8.9. Compensationinterface
Tool compensation interface shows tool compensation info of the system, including tool length
compensation,toolradius compensationand other input variables.The compensationmethodis described
below.
Toentertoolcompensationinterface:

Mseriestoolcompensationinterfacehastwocompensationvariables,i.e.toollengthcompensationand
tool radius compensation; corresponding
to G43, G44 and G41, G42; enter compensation value to
corresponding compensationnumber,andtransfer thecompensation number inNCprogramto realizethe
compensation.Toolcompensationnumbershave36variables.
Toolcompensationinterfaceisshownbelow:

ToolCompensationParameterSettingInterface
[Coordinates/COORD]
[Compensation]
