BZ001M056A ADT‐DK300A/400A Engraving Machine

106
Authority : Operationadminorhigher
Default : 0
Effectivetime : Instant
Note :
Purposeandfunctiontobespecified


10.3. Axisparameterconfiguration(P2.)
001 
X_ServoAlarmInELevel
002 
Y_ServoAlarmInELevel
003 
Z_ServoAlarmInELevel
004 
A_ServoAlarmInELevel
005 
X_ServoResetOutELeve
006 
Y_ServoResetOutELeve
007 
Z_ServoRes etOutELeve
008 
A_ServoResetOutELeve
Range : 0~1
Unit : LOGICVOLTAGELEVEL
Authority : SuperAdmin
Default : 1,1
Effectivetime : Instant
Note : Adapt tothe interface parameters ofselectedservo drive;pleaserefer
to interface voltage level description of servo for specific parameter
settings.Servoalarmeff ectivelevelcanbeset
to0forsteppermotor,or
else servo alarm will be generated because the port level read by the
systemis1.Reseteffectivelevelrefersthatthesystemwilloutputalarm
resetsignalfrompulseportiftheuserpressestheResetkeywhenservo
alarmoccurs.

009 
X_ECZHomeEnable
010 
X_ECZHomeELevel
011 
Y_ECZHomeEnable
012 
Y_ECZHomeELevel
013 
Z_ECZHomeEnable
014 
Z_ECZHomeELevel
