8.10. Workpiececoordinatesystemsettinginterface
Thecoordinatesinterfaceshowscoordinatesysteminfo,includingcoordinatesystemandcompensation.
Inthemaininterface,press[Coordinate]toentercoordinatesystem.

Workpiececoordinatesystem
Displayworkpiececoordinatesystem,i.e.theoffsetofworkpiecehomepositionandmachinetoolhome
position. Totally six basic workpiece coordinate systems (G54~G59) and nine
extension coordinate systems
(G591~G599)areavailable.

Toenterworkpiececoordinatesysteminterface:

Theworkpiececoordinatesysteminterfaceisshownbelow:

WorkpieceCoordinateSystemSettingInterface
[Coordinates/COORD]
[CoordinateSystem]
