Whentheprincipalaxisispositive/reverserotatingandexecutesM04/M03directly,thesystemfirststops
positive/reverserotatingandthenexecutesM04/M03instruction;
P ositive/reverse rotating of principal is stopped while emergency stop and other outputs can be set
accordingtosystemparameters.
3.6 Workingcoordinatesystemsettings(toolsetting)
ToolsettingisthemainoperationandimportantskillduringCNCprocessing.Undercertainconditions,
tool setting precision can determine the processing precision of parts, and the tool setting efficiency also
affects the CNC processing efficiency directly. DK300A and DK400A realize tool setting through G54‐G59
coordinatesystem.
Workpiececoordinatesystem
settingmethod
3.6.1. Entercurrentpositiontospecifiedcoordinatesystemdirectly(allaxes)
1.Press  toenterthecoordinatesysteminterface.Thebackgroundofselectcoordinatesystemis
white.

2.Then,press
,  toselectthecoordinatesystem,e.g.G54.

