BZ001M056A ADT‐DK300A/400A Engraving Machine
63
10. Systemparameters
According to occasions and functions, the parameters contain General parameters, IO configura tion
parameters,managementparametersandcoordinatesettingparameters.
Generalparametersarecomplete,andcontainbasicoperationandusagesettingsofthecontroller,includingprincipalaxis,
handwheel,home,toolmagazine,etc.;
IOconfigurationparametersaremainlyusedformachineinstallationandtest,adaptingtotheinterfacecharacteristicsof
machinetoolandmotordrive;
Coordinatesettingparametersaretoolsettingconfigurationin[Coordinate]interface;
(1)Itisrequiredtoconfirmuseridentitytomodifytheparametertable.Thecontrollerhastwolevelsof
userauthority,whicharesuperuserandoperator;superusercanmodifyallparametersanduserpasswords;
while operator only can operate the parameters that require modification; in P3.1 of management
parameters,
thesystementersthecorrespondingmodeautomaticallyaccordingtotheenteredpassword.
(2) According to the application, the parameters will tak e effect immediately or after restarted; the
parametersthatrequirerestartaremarkedwith<●>.
(3) Certainparameters areset in binary system (parameter descriptor has bit symbol); the
conversion
betweenbinarysystemanddecimalsystemfollows:
Bit0:Setto1tocorrespondtodecimal1;
Bit1:Setto1tocorrespondtodecimal2;
Bit2:Setto1tocorrespondtodecimal4;
Bit3:Setto1tocorrespondtodecimal8;
Bit4:Setto1tocorrespondto
decimal16;
Bit5:Setto1tocorrespondtodecimal32;
Bit6:Setto1tocorrespondtodecimal64;
