Thespecificoperationfollows:
(1)Pressthemodeswitchkey[
](thiskeyiscomposite,andyoucanpressitrepeatedlytoswitch
themodes)toselectthesinglestepoperation;
⑵ Press composite keys [
], [ ]; [ ], [ ]; [ ], [ ]; [ ],
[
]innumbersareatomovethetoolforafixeddistancealongtheselectedaxis.Thisdistance
iscontrolledbyfourrates(1.000,0.100,0.010,0.001)(unit:mm).Toselectpulseincrement,press
and keyinthe[Position]interface.
3.4 Handwheelfeeding
In handwheel mode, rotate the handwheel to make the machine perform single step or continuous
motion.Determinethefeed bytestingthehandwheelsignalofthehandheldbox.Inhandwheelmode,the
feedingaxisandfeedingunitaredeterminedbytheaxisselectionsignalofthehandheldbox.
Thehandwheelfeeding
stepfollows:
⑴ Pressthemodeswitchkey[
]toselecthandwheeloperation;
(2)Rotatethedipswitchonthehandwheeltoselecthandwheelaxis(X,Y, Z,A);
(3)Rotatetheincrementdipswitchonthehandwheeltoselectthemovingamount(0.1,0.01,0.001);
(4) Rotate the handwheel to move the machine tool. The tool moves certain
distance every time you
rotatethehandwheelforascale.(Forexample,ifyouselectXaxisinstep(2)andselect0.01instep(3),the
tool moves 0.01mm every scale). Rotate the handle continuously to move the machine tool on this axis
continuously.
) Note:
Thehandwheelfeedingmodecontrolsonlyonecoordinateaxiseverytime;thefasterthehandwheelrotates,thefaster
themachinetoolmoves.
3.5 Manualauxiliaryfunctionoperation
Coolanton/off
To Next Page
