BZ001M056A ADT‐DK300A/400A Engraving Machine



148

Since differential connection is used in most cases, please refer to differential mode for the pulse

connection. Most servo drives require 12‐24V power supply, and the 24V power provided by pin 10, 11 is

available.Thespecificconnectiondependsonservodrive.Pleasecontactusifyouhav eanyquestion.



0 Caution

EithertwoofPU+,PU‐,DR+andDR‐shouldn’tbeconnected,orelsethepulseinterfacemaybedamaged.



11.2.2.  Digitalinputinterface(XS5)

Thedigitalinputinterfacecontainsthehardlimitsignalofeveryaxis,andthedefinitionfollows:


