BZ001M056A ADT‐DK300A/400A Engraving Machine

36
Thestepofself‐diagnosisfo llows:
(1)Inthemainmenu,press[Diagnosis]toenterthediagnosisinterface;
(2)Select[Input]toentertheinputdiagnosisinterface, orselect[Output]toentertheoutputdiagnosis
interface;
(3)Outputdiagnosis:Ineditmode,pressthedirectionkeystoselecttheoutputport,
andpress[EOB]to
switchtheoutputlevelofcorrespondingoutputport;
(4)Inputdiagnosis:Whencertaininputsignalisvalid,thecorrespondingareaonthescreenflashes.






7. Program saving&editing
7.1 Savingtheprograminthememory
7.1.1. Keypadinput(newprogram)
Createnewprograminthememorywiththekeypad,andthestepfollows:
Inthemainmenu,press[Edit]toenterprogrameditinterface;
Press[File]toenterfileoperationinterface;
Select[New]tocreateanewfile;
Enter the file name and press [EOB] to confirm and create a new
 program in current directory in the
memory,andloadintothesystembydefault;
Select[Close]toexit[Edit]interface;
Ineditmode,entertheprogramcontent;
Aftereditingallprograms,press[Reset]tosavetheeditedprogramsintothesystemmemory.
