BZ001M056A ADT‐DK300A/400A Engraving Machine

131

015 
IN0‐‐‐‐‐‐‐‐Inputwir eNo.
… 
…
038 
IN23‐‐‐‐‐‐‐InputwireNo.
Range : 1~24
Unit : None
Authority : SuperAdmin
Default : Theporttableinthemanual
Effectivetime : Instant
Note :
InputterminalNo.configurationparameter
Term inal No. is the object of the system to control IO, e.g. X external
home signal test, and the system tests terminal No. IN0, which
correspondstoinputwire1bydefault,andthusthesystemtestsinput
pin1 indirectly; by default, the terminal No. is assigned to wire No. 
according to the IO relationship in the manual; however, this
relationshipisn’tconstant,andyoucanspecifyintheseparametersand
reassigna
terminalNo.toanyinputport;
Forexample,ifyouset10inparameter042,thesystemwilltestpin10
insteadofpin1whenittestsXhomesignalduringhomeoperation.

039 
OUT0‐‐‐‐‐‐‐‐OutputwireNo.
… 
…
062 
OUT23‐‐‐‐‐‐‐InputwireNo.
Range : 1~24
Unit : None
Authority : SuperAdmin
Default : Theporttableinthemanual
Effectivetime : Instant
Note : Output terminal No. configuration is same as input terminal
configuration.OutputterminalNo.andwireNo.aremapped
063  SafeSignal
Range : 0~23
Unit : None
Authority : Operationadminorhigher
Default : =========
Effectivetime : Instant
