Adtech ADT-DK300A User Manual

BZ001M056A ADT‐DK300A/400A Engraving Machine

146
8 ECZ‐
EncoderphaseZinput‐
9 PUCOM
Controllerforsingleendinput
10 24V+
Internallyprovided24Vpowersupply,directlyconnected
to24Vpowersupplyofthecontroller 
11 24V‐
12 ECA+ EncoderphaseAinput+
13 ECA‐ EncoderphaseAinput‐
14 ECB+ EncoderphaseBinput+
15 ECB‐ EncoderphaseBinput‐
Standardpulsewiringdiagram

ThiswiringissuitableforDK300A/400Acontroller;
Stepmotordrivecabletodifferentialinput
Adtech CNC drive is for reference, all of which use differential input mode. This mode has strong
anti‐interferenceandisrecommended.PleaserefertothefigurebelowfortheconnectionofCNCwithstep
motordrive
andstepmotor
