Total Access 600R System Manual Section 6 ADTRAN Utilities
61200600L1-1A © 2002 ADTRAN, Inc. 185
2. VT100 UTILITY
Use the VT100 to configure a unit which is directly connected to a PC. The VT100 display is almost
identical to the Telnet display.
For a detailed description of how to work within the terminal menu, refer to Navigating the Terminal
Menus in the User Interface Guide section of this manual. If you need help setting up the unit for a VT100
session, refer to the Detailed Level Procedures section of this manual.
VT100 menus include
SESSION, EDIT, PORT, OPTIONS, CAPTURE, and HELP (see the menu tree in Figure 2).
Figure 2. VT100 Menu Tree
Session Menu
Opens VT100 terminal emulation session.
Connect
Opens a specified serial port for a VT100 session.
Disconnect
Closes a specified serial port at the end of a VT100 session.
File Transfer
Uploads and downloads files to and from the unit.
Connect
Session Disconnect
File Transfer XMODEM CRC
Exit ASCII Cfg Files Send Cfg File
Edit Copy
Paste
Port Settings
Refresh Screen Transmit Wakeup
Connect Transmit Refresh
VT100 Options Colors
Local Echo BackGround
Auto Repeat Bold
Tex t
File Start Cfg Capture
Capture Buffer Size Stop Cfg Capture
Save Buffer As
Screen Capture
Help Contents
About
