Section 4 User Interface Guide Total Access 600R System Manual
76 © 2002 ADTRAN, Inc. 61200600L1-1A
L2 PROTOCOL (T1[0] - FRE) > STATUS
View the L2 Protocol status for the T1 interface using the Frame Relay protocol.
L2 PROTOCOL (T1[0] - FRE) > STATUS > PORT
View the Frame Relay statistics on the WAN port.
L2 PROTOCOL (T1[0] - FRE) > STATUS > PORT > PORT INDEX
Integer used for identifying DLCIs on an interface. A single DLCI will always be port index 0. Subsequent
DLCIs will have incrementing port indices.
L2 PROTOCOL (T1[0] - FRE) > STATUS > PORT > SIGNAL STATE
Displays “up” when the unit is communicating with the Frame Relay switch; otherwise displays “down”.
L2 PROTOCOL (T1[0] - FRE) > STATUS > PORT > TX FRAMES
Total frames transmitted out the WAN port.
L2 PROTOCOL (T1[0] - FRE) > STATUS > PORT > RX FRAMES
Total frames received on the WAN port.
L2 PROTOCOL (T1[0] - FRE) > STATUS > PORT > TX BYTES
Total bytes transmitted out the WAN port.
L2 PROTOCOL (T1[0] - FRE) > STATUS > PORT > RX BYTES
Total bytes received on the WAN port.
L2 PROTOCOL (T1[0] - FRE) > STATUS > PORT > FULL STATUS TX FRAMES
Number of full status frames transmitted out the WAN port.
L2 PROTOCOL (T1[0] - FRE) > STATUS > PORT > FULL STATUS RX FRAMES
Number of full status frames received on the WAN port.
L2 PROTOCOL (T1[0] - FRE) > STATUS > PORT > LINK INTEGRITY STATUS TX FRAMES
Number of Link-Integrity (LI) only frames transmitted out the WAN port.
L2 PROTOCOL (T1[0] - FRE) > STATUS > PORT > LINK INTEGRITY STATUS RX FRAMES
Number of LI only frames received on the WAN port.
L2 PROTOCOL (T1[0] - FRE) > STATUS > PORT > DROP UNKNOWN DLCI
Number of frames received that were not associated with any known PVC.
