Total Access 600R System Manual Section 4 User Interface Guide
61200600L1-1A © 2002 ADTRAN, Inc. 77
L2 PROTOCOL (T1[0] - FRE) > STATUS > PORT > DROP INVALID DLCI
Number of frames received that had illegal DLCIs.
L2 PROTOCOL (T1[0] - FRE) > STATUS > PORT > CLEAR STATS
Selecting this activator will clear the port Frame Relay Statistics.
L2 PROTOCOL (T1[0] - FRE) > STATUS > PVC'S
View the Frame Relay status on a per-PVC basis.
L2 PROTOCOL (T1[0] - FRE) > STATUS > PVC'S > DLCI
The DCLI number identifies the virtual circuit being monitored.
L2 PROTOCOL (T1[0] - FRE) > STATUS > PVC'S > STATE
The state of the virtual circuit:
L2 PROTOCOL (T1[0] - FRE) > STATUS > PVC'S > TX FRAMES
Number of Frame Relay packets that have been transmitted via this DLCI.
L2 PROTOCOL (T1[0] - FRE) > STATUS > PVC'S > RX FRAMES
Number of Frame Relay packets that have been received via this DLCI.
L2 PROTOCOL (T1[0] - FRE) > STATUS > PVC'S > TX BYTES
Number of Frame Relay bytes that have been transmitted via this DLCI.
L2 PROTOCOL (T1[0] - FRE) > STATUS > PVC'S > RX BYTES
Number of Frame Relay bytes that have been received via this DLCI.
L2 PROTOCOL (T1[0] - FRE) > STATUS > PVC'S > DE COUNT
Number of packets received on this DLCI with the Discharge Eligible (DE) bit set.
INACTIVE
The circuit exists but has been deactivated by the Frame Relay
switch.
EXISTS
The circuit exists at this point and should be activated soon.
ACTIVE
The circuit is fully active.
OFF
The circuit has been turned off by the DLCI mapping active
selection.
