Section 3 Network Turnup Procedure Total Access 600R System Manual
32 © 2002 ADTRAN, Inc 61200600L1-1A
• 2 Mounting Brackets (P/N 3265421@C)
• 4 Screws (P/N 3276003003)
• RJ-45 to DB-9 Adapter (P/N 3196ADPT001)
• The Total Access 600R base unit.
4. GROUNDING INSTRUCTIONS
The following provides grounding instruction information from the Underwriters’ Laboratory UL 60950
Standard for Safety of Information Technology Equipment Including Electrical Business Equipment, with
revisions dated March 15, 2002.
AC Power
The attachment-plug receptacles in the vicinity of the product or system are all to be of a grounding type,
and the equipment grounding conductors serving these receptacles are to be connected to earth ground at
the service equipment.
5. SUPPLYING POWER TO THE UNIT
AC Powered Systems
The AC powered unit comes equipped with a detachable power cord with a 3-prong plug for connecting to
a grounded power receptacle. As shipped, the unit is set to factory default conditions. After installing the
chassis, the unit is ready for power-up. To power-up the unit, ensure that the unit is properly connected to
an appropriate power source.
Customers must supply the Ethernet cable.
• This unit shall be installed in accordance with Article 400 and 364.8 of the NEC NFPA
70 when installed outside of a Restricted Access Location (i.e., central office, behind a
locked door, service personnel only area).
• Power to the unit’s AC system must be from a grounded 90-125 VAC, 60 Hz source.
• The power receptacle uses double-pole, neutral fusing.
• Maximum recommended ambient operating temperature is 45 ºC.
