Section 4 User Interface Guide Total Access 600R System Manual
82 © 2002 ADTRAN, Inc. 61200600L1-1A
BRIDGE > CONFIG > INTERFACES (T1[0]) > SUB-INTERFACE
The T1 sub-interface is PPP [0.0] if the L2 PROTOCOL is set for PPP. The [0.0] represents the T1 physical
and logical ports, respectively. This is a read-only field. The T1 sub-interface is
FRE [0.X] if the L2
P
ROTOCOL is set for FRAME RELAY. The [0.X] represents the T1 physical and logical ports, respectively.
The T1 physical port is always 0. The X represents the Frame Relay logical port and will be a number
between 0-9 corresponding to the interface number under
L2 PROTOCOL > CONFIG > DLCI MAPPING. This is
a read-only field.
BRIDGE > CONFIG > INTERFACES (ETH[1])
Configure the Ethernet Bridging parameters from this menu.
BRIDGE > CONFIG > INTERFACES (ETH[1]) > SUB-INTERFACE
The Ethernet sub-interface is 802.3[1.0]. The [1.0] represents the Ethernet physical and logical ports,
where 1 is the physical port and 0 is the logical port assigned to the Ethernet interface. This is a read-only
field.
BRIDGE > CONFIG > BRIDGE TABLE
Configure the bridge table parameters from this menu.
BRIDGE > CONFIG > BRIDGE TABLE > BRIDGE TABLE AGING (0-65535)
BRIDGE TABLE AGING is how soon an entry ages out of the Bridge table (in minutes). Default is 5.
BRIDGE > STATUS
View the bridging statistics from this menu.
BRIDGE > STATUS > BRIDGE TABLE
View the bridge table status from this menu.
BRIDGE > STATUS > BRIDGE TABLE > MAC ADDRESS
Ethernet address for device learned. This is a read-only field.
BRIDGE > STATUS > BRIDGE TABLE > LOCATION
Location indicates if it is LAN or WAN. This is a read-only field.
The ETH[1] interface will not appear as a bridge interface entry if the mode is set to route
IP.
