Total Access 600R System Manual Section 4 User Interface Guide
61200600L1-1A © 2002 ADTRAN, Inc. 79
L2 PROTOCOL (T1[0] - AUTO) > STATUS > TX PKTS
Number of packets transmitted out of the WAN port.
L2 PROTOCOL (T1[0] - AUTO) > STATUS > RX PKTS
Number of packets received on the WAN port.
L2 PROTOCOL (T1[0] - AUTO) > STATUS > TX BYTES
Number of bytes transmitted out of the WAN port.
L2 PROTOCOL (T1[0] - AUTO) > STATUS > RX BYTES
Number of bytes received out the WAN port.
L2 PROTOCOL (T1[0] - AUTO) > STATUS > CLEAR STATS
Selecting this activator will clear the statistics.
L2 PROTOCOL (ETH[1])
Configure the L2 PROTOCOL parameters and view the status of the Ethernet interface from this menu.
L2 PROTOCOL (ETH[1]) > PROTOCOL
Displays the L2 Protocol for the 10/100BASET Ethernet port. Currently only 802.3 is supported.
L2 PROTOCOL (ETH[1]) > CONFIG
Configure the mode for this 10/100BASET Ethernet port from this menu.
L2 PROTOCOL (ETH[1]) > CONFIG > MODE
The mode identifies how the data will be forwarded. The choices are:
The default is
ROUTE IP.
The 1 in ETH[1] represents a physical port. The Ethernet physical port is always 1.
ROUTE IP
All IP data will be routed
BRIDGE ALL
All data will be bridged
ROUTE IP/BRIDGE OTHER
All IP data will be routed. All other data will be bridged.
