Section 4 User Interface Guide Total Access 600R System Manual
80 © 2002 ADTRAN, Inc. 61200600L1-1A
L2 PROTOCOL (ETH[1]) > STATUS
View the L2 Protocol statistics for the 10/100BASET Ethernet port from this menu.
L2 PROTOCOL (ETH[1]) > STATUS > TX PACKETS
Total number of packets transmitted out the Ethernet port.
L2 PROTOCOL (ETH[1]) > STATUS > RX PACKETS
Total number of packets received from the Ethernet port.
L2 PROTOCOL (ETH[1]) > STATUS > TX ERRORS
Total number of transmit errors encountered on Ethernet port.
L2 PROTOCOL (ETH[1]) > STATUS > SINGLE COLLISIONS
Total number of single collisions before successful transmission.
L2 PROTOCOL (ETH[1]) > STATUS > MULTIPLE COLLISIONS
Total number of multiple collisions before successful transmission.
L2 PROTOCOL (ETH[1]) > STATUS > EXCESSIVE COLLISIONS
Total number of collisions that resulted in packet being dropped.
L2 PROTOCOL (ETH[1]) > STATUS > DEFERRED TRANSMISSIONS
Total number of packets deferred due to collisions.
L2 PROTOCOL (ETH[1]) > STATUS > CARRIER SENSE ERRORS
Total number of carrier sense errors encountered (no link integrity).
L2 PROTOCOL (ETH[1]) > STATUS > RX ERRORS
Number of packets received in error and dropped.
L2 PROTOCOL (ETH[1]) > STATUS > CRCS
Number of packets detected with CRC errors.
L2 PROTOCOL (ETH[1]) > STATUS > RX COLLISIONS
Number of collisions which occurred during reception.
L2 PROTOCOL (ETH[1]) > STATUS > NON-ALIGNED
The NON-ALIGNED parameter is set when the number of bits received is not divisible by 8.
