AC Power Connection
Each unit includes an auto ranging 90-125 VAC, 60 Hz power supply with a 3-prong removable cable.
Connect the power supply to a standard 120 VAC, 60 Hz electrical outlet for proper operation.
5. DB-9 TO RJ ADAPTER
The DB-9 to RJ adapter is used to connect a PC or VT100 terminal to the CRAFT port. The adapter pinout
is shown in Table 5.
Table 5. DB-9 to RJ Adapter Pinout
DB-9 RJ-45 DESCRIPTION
25 TX Data
3 3 RX Data
51 GND
Note: All other pins are unused.
