Section 4 User Interface Guide Total Access 600R System Manual
62 © 2002 ADTRAN, Inc. 61200600L1-1A
SYSTEM UTILITY > SYSTEM UTILIZATION > PERFORMANCE > CURRENT AVG CPU UTILIZATION
CURRENT AVG CPU UTILIZATION is the running total of CPU utilization since the last clear.
SYSTEM UTILITY > SYSTEM UTILIZATION > PERFORMANCE > CLEAR STATS
This activator will clear all the system utilization performance stats.
SYSTEM UTILITY > PING
Activate the ping test and define the ping packet characteristics from this menu.
SYSTEM UTILITY > PING > START/STOP
Activator to start and cancel a ping test.
SYSTEM UTILITY > PING > HOST ADDRESS
IP address or domain name (if DNS is configured) of device to receive the ping. The factory default is no
entry in the host address field.
SYSTEM UTILITY > PING > SOURCE ADDRESS
Selects whether the ping packet should use the INTERFACE address or the NAPT (if that interface uses NAT)
as the source address of the ping packet. This is the address that is used for ICMP requests.
INTERFACE
means it will use the IP address associated with the WAN for outgoing packets and the Ethernet IP address
for ICMP requests made on the LAN.
NAPT ADDRESS will replace the WAN IP address with the NAPT
address for outgoing ICMP requests. Default is
INTERFACE.
SYSTEM UTILITY > PING > SIZE (40-1500)
Total size of the ping to send. Range is 40 to 1500 bytes. The default is 64.
SYSTEM UTILITY > PING > # OF PACKETS
Total packets to send every 2 seconds. Setting this to 0 allows the client to ping continuously. The default is
5.
SYSTEM UTILITY > PING > # TRANSMITS
Total packets sent (read-only).
SYSTEM UTILITY > PING > # RECEIVES
Total packets received (read-only).
Only one ping session can be active at a time.
