Section 4 User Interface Guide Total Access 600R System Manual
42 © 2002 ADTRAN, Inc. 61200600L1-1A
2. TERMINAL MENU AND SYSTEM CONTROL
Selecting the Appropriate Menu
The terminal menu is the access point to all other operations. Each terminal menu item has several
functions and submenus that identify and provide access to specific operations and parameters. Use the
chart below to help select the appropriate terminal menu.
Paste the item stored in the clipboard, if the information is compatible.
You must confirm all pastes except those to a single editable field.
P
Increment the value of certain types of fields by one when you paste information into
those fields.
>
Decrement the value of certain types of fields by one when you paste information into
those fields.
<
Insert a new list item.
For example, add a new item to the T
ELNET USER LIST connection list by pressing <I>
while the cursor is over the index number.
I
Delete a list item.
For example, delete an item from the T
ELNET USER LIST connection list by pressing <D>
while the index number is active.
D
To do this... Go to this menu...
Review and monitor general system information S
YSTEM INFO
Set up the management, syslog, and network time SYSTEM CONFIG
Upgrade firmware, do config transfers, ping, traceroute, reset unit, and access
terminal mode
S
YSTEM UTILITY
Configure and monitor the T1 and Ethernet interfaces. INTERFACES
Configure and monitor the L2 Protocol for the T1 and Ethernet interfaces L2 PROTOCOL
Configure and monitor bridging parameters BRIDGE
Define, configure, and monitor all router functions ROUTER
Configure the filter defines and Radius server SECURITY
Configure and apply DS0 maps DS0 MAPS
To do this... Press this
key...
