Total Access 600R System Manual Section 4 User Interface Guide
61200600L1-1A © 2002 ADTRAN, Inc. 95
ROUTER > STATUS
View the IP ROUTES, IP STATS, and ARP CACHE statistics from this menu.
ROUTER > STATUS > IP ROUTES
This lists the contents of the unit’s IP route table.
ROUTER > STATUS > IP ROUTES > IP ADDRESS
Network or host destination address.
ROUTER > STATUS > IP ROUTES > NETMASK
Network mask applied to the destination address.
ROUTER > STATUS > IP ROUTES > GATEWAY
Host or router to receive this packet.
ROUTER > STATUS > IP ROUTES > PORT
Port gateway is located on:
ROUTER > STATUS > IP ROUTES > USE
Number of times the unit has referenced the route.
UDP PORT TYPE
The choices are STANDARD (def) and SPECIFIED. The following standard UDP protocols are relayed
when set: DHCP, TFTP, DNS, NTP (Network Time Protocol, port 123), NBNS (NetBios Name
Server, port 137), NBDG (NetBIOS Datagram, port 138), and BootP. When
SPECIFIED is set, the
UDP port (1 to 65535) can be specified in the UDP Port columns (up to three per server).
UDP PORT 1, 2, 3
Used for specifying UDP ports to be relayed. These fields only apply when UDP PORT TYPE is set to
SPECIFIED. Default is 0.
LOCAL
Sent directly to the unit’s router
ETH0
The unit’s Ethernet port
WAN0
The unit’s first PPP bundle
FR 0 . . . FR 9
The unit is connected up to 10 DLCIs.
