61200600L1-1A © 2002 ADTRAN, Inc. 161
LOADING THE CURRENT CONFIGURATION USING TFTP
Introduction
The unit supports configuration uploads from a unit (via the 10/100BASET Ethernet port) to a TFTP server
located on the network or a TFTP server accessible across the WAN. This DLP provides the steps for a
successful configuration upload using the
10/100BASET Ethernet port and a TFTP server.
Tools and Materials Required
• A PC with a Telnet client software
• A TFTP server accessible on the local network (a TFTP server is provided with the unit as part of the
ADTRAN Utilities software) or a TFTP server accessible across the WAN
• VT100 compatible terminal or computer with terminal emulation software
• Appropriate cable to connect terminal to the unit (customer-provided)
• DB-9 female to RJ-45 female adapter for connecting to the
CRAFT port on the rear of the unit. This
adapter is ADTRAN-proprietary and is shipped with the unit.
• Ethernet cable from
10/100BASET port on the unit to a hub (customer-provided)
• Use Ethernet crossover if going from the unit to a PC (customer-provided).
To prevent electrical shock, do not install equipment in a wet location or during a
lightning storm.
