Total Access 600R System Manual Section 4 User Interface Guide
61200600L1-1A © 2002 ADTRAN, Inc. 119
Appendix A. Configuring the Unit for Routing
Initial Setup
Before the unit can be configured for routing, the DS0s must be mapped.
DS0 Mapping
Setting up Routing Options
The unit can support IP routing and bridging. These procedures are described on the pages that follow.
DS0 Mapping Instructions
Step Action
1. From the Main menu, select DS0 M
APS.
2.
Verify that the A
CTIVE MAP is set to either MAP 1 or MAP 2. This is the map that
is actively running on the unit. The unit has the ability to store two maps.
• To edit the current map, press E
NTER on EDIT/VIEW MAP 1 to view the map.
(If Map 1 is the Active Map)
• To edit the standby map, press E
NTER on EDIT/VIEW MAP 2 to view the map.
(If Map 2 is the Active Map)
The T1 line entering the unit is broken up into 24 DS0s or channels. At least
one DS0 needs to be mapped to the router in order to use the unit for routing
purposes.
3.
Scroll down to the DS0 that will be mapped. (Any DS0 can be mapped to the
router.)
4. Set the S
ERVICE for the DS0 that you are mapping to TA 600R.
5. Set the P
ORT of the DS0 that you are mapping to ROUTER 64K or ROUTER 56K.
6.
Map all the DS0s as desired, and exit this menu by pressing the left arrow
button. Your changes will automatically save when exiting the map.
7.
Make sure the A
CTIVE MAP is set to the correct map (the map you want
running) before exiting the DS0 M
APS menu.
