Section 4 User Interface Guide Total Access 600R System Manual
120 © 2002 ADTRAN, Inc. 61200600L1-1A
IP Routing
After completing the DS0 mapping, there are three remaining steps required for the unit to be used for IP
Routing: (1) Ethernet Interface Configuration, (2) T1 Interface Configuration, and (3) Default Gateway
Configuration. All of these procedures are described in the pages that follow.
Router Ethernet Interface Setup
Router Ethernet Interface Setup Instructions
Step Action
1
From the Main menu, select R
OUTER, select CONFIG, select INTERFACES and
then select ETH [1] S
ETUP and press ENTER.
2
Press Enter on the P
RIMARY IP [+] option to enter primary Ethernet
configuration.
3 Set the IP A
DDRESS of the Ethernet port.
4 Set the S
UBNET MASK of the Ethernet port.
5
RIP on the Ethernet is disabled by default. If RIP needs to be enabled, press
Enter on RIP [+].
6 Press E
NTER on VERSION and select V1 or V2 to activate RIP.
7
Press the down arrow and select the appropriate RIP
METHOD, DIRECTION, and
V2
SECRET (where applicable).
8
Press the left arrow key to return to the Ethernet menu showing P
RIMARY IP and
S
ECONDARY IPS.
9
If the unit needs additional secondary IP addresses, press Enter on
S
ECONDARY IPS [+].The unit supports up to 5 additional LAN segments.
Enter each additional secondary IP address and subnet mask. Press "I" to
insert additional entries.
