Total Access 600R System Manual Section 4 User Interface Guide
61200600L1-1A © 2002 ADTRAN, Inc. 121
Router T1 Interface Setup
Before configuring the Router T1 Interface, choose L2 PROTOCOL and select PPP, FRE, or AUTO. Setup
instructions for the
PPP and FRE are described on the following pages. For information on setting the L2
P
ROTOCOL to AUTO, reference DLP-014, Unit Installation Using The Auto-Config Feature.
Router T1 Interface Setup Instructions when L2 Protocol = PPP
Step Action
1 From the Main menu, select L2 P
ROTOCOL and press ENTER.
2 Set the T1 [0] interface protocol to PPP.
3 Press Enter on the C
ONFIG [+] option. Verify mode is ROUTE IP.
4
Press Enter on the A
UTHENTICATION [+] option if you wish to change options
related to how the link is established. Default is T
X METHOD = NONE and RX
M
ETHOD = NONE. If TX METHOD and RX METHOD are set to any option other
than N
ONE, TX/RX USERNAME and PASSWORD options will appear.
5 Left arrow back to the Main menu.
6
Select router, select C
ONFIG, select INTERFACES, and select T1 [0] SETUP. Enter
WAN information:
• Far-End IP Address The far-end WAN IP address from the unit.
• IP Netmask The subnet mask for this WAN link
• Local IP Address The local WAN IP address for the unit.
The other config items can be left at the defaults.
7
For NAT configuration, please see the IP Routing with NAT section of this
appendix. On page 123.
To Next Page
