Section 4 User Interface Guide Total Access 600R System Manual
122 © 2002 ADTRAN, Inc. 61200600L1-1A
Router T1 Interface Setup Instruction when L2 Protocol = Frame Relay (FRE)
(required if the unit is to be used for Frame Relay IP Routing on the WAN interface)
Step Action
1 From the Main menu, select L2 P
ROTOCOL and press ENTER.
2 Set the T1 [0] interface protocol to FRE.
3 Press Enter on the C
ONFIG [+] option.
4
Set the M
AINTENANCE PROTOCOL to ANNEX D (ANSI), ANNEX A (q 933a), LMI,
OR STATIC (no sig).
The MAINTENANCE PROTOCOL should be set based on the Frame Relay
switch.
5
Down arrow and press Enter on DLCI M
APPING [+]. Right arrow one time to
create an entry.
6 Set A
CTIVE to YES.
7 Set DLCI to the DLCI number.
8 Set mode to R
OUTE IP.
9
Left arrow back to the main menu. Select R
OUTER, select CONFIG, select
INTERFACES, and select T1 [0] SETUP. Set ACTIVE to YES.
10
Set A
DDRESS MODE to USER SPECIFIED and enter a FAR-END IP ADDRESS. This
will force the unit to not use IARP.
11 Enter the IP N
ETMASK.
12
Enter the L
OCAL IP ADDRESS for the unit. The other config items can be left at
the default values.
13
For NAT configuration, please see the IP Routing with NAT section of this
appendix, on page 133.
