Section 4 User Interface Guide Total Access 600R System Manual
84 © 2002 ADTRAN, Inc. 61200600L1-1A
ROUTER > CONFIG > INTERFACES (ETH[1]) > SUB-INTERFACE
The Ethernet sub-interface is 802.3[1.0]. The [1.0] represents the Ethernet physical and logical ports,
where 1 is the physical port and 0 is the logical port assigned to the Ethernet interface. This is a read-only
field.
ROUTER > CONFIG > INTERFACES (ETH[1])> SETUP
Configure the Ethernet addressing, RIP, and Proxy ARP from this menu.
The Ethernet port will always appear in the ROUTER > CONFIG > INTERFACES table
regardless of the L2 Protocol mode setting.
PRIMARY IP
This is used to set up the IP addresses for the LAN on the unit.
IP ADDRESS
The IP address assigned to the unit's Ethernet port is set here. This address must be unique within
the network. Default is
10.0.0.1.
SUBNET MASK
This is the IP network mask that is to be applied to the unit's Ethernet port. Default is
255.255.255.0.
RIP
Use this menu to enable RIP on the LAN interface.
VERSION
Enables or disables RIP and specifies the RIP Protocol. Choices are; OFF (which disables
RIP),
V1 (RIP Version 1) or V2 (RIP Version 2). The default is OFF.
METHOD
Specifies the way the RIP Protocol sends out its advertisements. The following options are
available:
SPLIT HORIZON (DEF)
Only routes not learned from this circuit are advertised.
POISON REVERSE
All routes are advertised, but the routes learned from this port
are “poisoned” with an infinite metric.
