Section 4 User Interface Guide Total Access 600R System Manual
86 © 2002 ADTRAN, Inc. 61200600L1-1A
ROUTER > CONFIG > INTERFACES (T1[0])
Configure the T1 interface parameters from this menu.
ROUTER > CONFIG > INTERFACES (T1[0])> SUB-INTERFACE
The T1 sub-interface is PPP [0.0] if the L2 Protocol is set for PPP. The [0.0] represents the T1 physical and
logical ports, respectively. This is a read-only field.
The T1 sub-interface is FRE [0.X] if the L2 Protocol is set for
FRAME RELAY. The [0.X] represents the T1
physical and logical ports, respectively. The T1 physical port is always 0. The X represents the Frame
Relay logical port and will be a number between 0-9 corresponding to the interface number under
L2 PROTOCOL > CONFIG > DLCI MAPPING. This is a read-only field.
ROUTER > CONFIG > INTERFACES (T1[0]) > SET-UP
Configure the addressing, address mode, MTU, NAT, and RIP parameters from this menu.
The 0 in T1[0] represents a physical port. The T1 physical port will always be 0.
The T1 interface will not appear in the ROUTER > CONFIG > INTERFACES table if the L2
P
ROTOCOL MODE is set for BRIDGE ALL. The T1 interface will not appear if a DLCI is not
entered in the
DLCI MAPPING table (L2 PROTOCOL (T1[0]-FRE) > CONFIG > DLCI MAPPING)
when the
L2 PROTOCOL is set to Frame Relay (FRE).
ACTIVE
This option allows this DLCI to be assumed as active (set to YES) and begin transmitting data
packets. If set to
NO, the interface will not be put in the route table and will not be seen by other
devices on the network. This can be set to
NO if waiting on future turnup from Frame Relay provider.
Default is set to
YES.
DLCI
(This option is only available when the L2 PROTOCOL is set to FRAME RELAY.) This DLCI is the
number associated with the virtual circuit on the T1 interface. This number corresponds to the DLCI
number in the
L2 PROTOCOL > CONFIG > DLCI MAPPING table.
