52
Configuring Auto-Send
1. From the Main Menu, select Settings > Capture to display the Capture settings screen.
2. Highlight and Select Auto-Send.
3. Use Arrow Keys to enable Auto-Send on 1st Capture key or on 2nd Capture key.
When Auto-Send is enabled, pressing Capture key from Live Image mode will initiate auto-focus (if
enabled), capture image, analyze pass/fail (if enabled), then send image and pass/fail results to paired
FlexScan OTDR.
1
2
3
1
2
3
