Understanding Event Table View Features
Event Table View may be accessed from either LinkMap
®
or Test Info View by touching the Event Table tab
Event Table View displays measurements for the currently
selected Link Summary, Event, or Section.
• Touch the desired Event icon (or Section) to learn more
details about that Event (or Section)
– Swipe or touch Left / Right Arrows
A
to
move to previous or next ber Section or Event.
• Touch Event Table tab
B
to view selected
Summary, Event, or Section details.
Event Table View
B
LinkMap View
A
