Agilent Technologies 83620B

Analog Power Sweep
Range: 0 20 dBm to maximum available p ower, can b e oset using
step attenuator.
External Leveling
Range
At External HP/Agilent 33330D/E Detector: 0 36 to +4 dBm
At External Leveling Input: 0 200  Vto 0 0.5 volts
Bandwidth
External Detector Mo de: 10 or 100 kHz (sw
eep speed and
mo dulation mo de dependent), nominal
Power Meter Mo de: 0.7 Hz, nominal
Source Match
(internally leveled), typical
6
< 20 GHz 1.6:1 SWR
< 40 GHz 1.8:1 SWR
< 50 GHz 2.0:1 SWR
6
Typically 2.0:1 SWR at frequencies b elow 50 MHz.
2c-6 Specifications
