Agilent Technologies 83620B

POWER 4
MENU
5
Programming Codes
SCPI: POWer[:LEVEL] < num > [lvl sux] or
MAXimum j MINimum j UP j DOWN
Analyzer: PL
See Also
4
ALC
5 , CONNECTORS,
NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN
Det Cal Menu , 4
FLTNESS ON/OFF
5 ,
NNNNNNNNNNNNNNNNNNNNNNNNNNNNN
Set Atten ,
NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN
Tracking Menu ,
NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN
Uncoupl Atten
\Programming Typical Measurements" in Chapter 1
POWER 4
MENU
5
Function Group
POWER
Menu Map
5
Description
This hardkey accesses the p ower function softkeys.
NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN
Fltness Menu
Accesses the softkeys in the atness
correction menu.
NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN
Power Offset Changes the displayed power to include
an oset, but do es not change the
output p ower of the swept signal
generator.
NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN
Power Slope
Activates the linear, power-per-frequency
mo de of p ower output, and makes RF
slop e (dB/GHz) the active function.
NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN
Power Sweep
Activates p ower sweep mo de and makes
power sweep (dB/swp) the active
function.
NNNNNNNNNNNNNNNNNNNNNNNNNNNNN
Set Atten Activates uncoupled attenuator as
the mo de of operation and makes the
attenuator value the active function.
NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN
Tracking Menu Accesses the softkeys in the tracking
calibration menu.
NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN
Uncoupl Atten Uncouples the attenuator from the ALC
system.
NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN
Up/Dn Power
Allows you to enter values for the p ower
level step size.
All RF p ower functions except for power level, atness on/o, and
RF on/o are contained in the p ower menu.
Operating and Programming Reference P-5
