1- 35
Making Measurements
Using Markers
Figure 1-23 Example of Setting the Stop Frequency Using a Marker
Setting the Center Frequency
1. Press and turn the front panel knob, or enter a value from the front panel keypad to
position the marker at the value that you want for the center frequency.
2. Press to change the center frequency value to the value of the active marker.
Figure 1-24 Example of Setting the Center Frequency Using a Marker
Setting the Frequency Span
You can set the span equal to the spacing between two markers. If you set the center frequency before you
set the frequency span, you will have a better view of the area of interest.
1. Press .
2. Turn the front panel knob, or enter a value from the front panel keypad to position the markers where you
