1-36
Making Measurements
Using Markers
want the frequency span.
Iterate between marker 1 and marker 2 by pressing and , respectively,
and turning the front panel knob or entering values from the front panel keypad to position the markers
around the center frequency. When finished positioning the markers, make sure that marker 2 is
selected as the active marker.
NOTE Step 2 can also be performed using and . However, when
using this method, it will not be possible to iterate between marker zero and marker 1.
3. Press to change the frequency span to the range between
marker 1 and marker 2.
Figure 1-25 Example of Setting the Frequency Span Using Marker
Setting the Display Reference Value
1. Press and turn the front panel knob, or enter a value from the front panel keypad to
position the marker at the value that you want for the analyzer display reference value.
2. Press to change the reference value to the value of the active marker.
