Agilent Technologies 8860 - To Install an Insulation Cup on the Packed Column Inlet

7 Maintaining the Packed Column Inlet
To Install an Insulation Cup on the Packed Column Inlet
Maintaining Your GC 107
To Install an Insulation Cup on the Packed Column
Inlet
1 Gather the following:
• No-hole ferrule
• Column nut
2 Install a plug (for example, a column nut with no-hole ferrule).
3 Push the cup spring to the right. Slide the cup over the inlet fitting so that the insulation at
the top of the cup is flush against the oven roof.
4 Place the spring into the groove in the inlet liner. Remove the column nut and no-hole
ferrule.
