11 Maintaining the ECD
Consumables and Parts for the ECD
174 Maintaining Your GC
Consumables and Parts for the ECD
See the Agilent catalog for consumables and supplies for a more complete listing, or visit the
Agilent Web site for the latest information (www.agilent.com/chem/supplies).
Table 25 ECD consumables and parts
Description Part number/quantity
Fused silica indented mixing liner G2397-20540
Makeup gas adapter G3433-63000
ECD wipe test kit 18713-60050
Insulation 19234-60715 (1/pk)
Nut, 1/4-inch Swagelok adapter 5180-4105 (10/pk)
Ferrule, graphitized Vespel, 1/4-inch 5080-8774 (10/pk)
Capillary column blanking nut 5020-8294
1/4-inch Detector adapter, for 1/8-inch packed columns 19301-80530
Table 26 Nuts, ferrules, and hardware for capillary columns
Column id (mm) Description Typical use Part number/quantity
.530 Ferrule, Vespel/graphite, 0.8-mm id 0.45-mm and 0.53-mm capillary columns 5062-3512 (10/pk)
Ferrule, graphite, 1.0-mm id 0.53-mm capillary columns 5080-8773 (10/pk)
Ferrule, graphite, 0.8-mm id 0.53-mm capillary columns 500-2118 (10/pk)
Column nut, finger-tight (for
0.53-mm columns)
Connect column to inlet or detector 5020-8293
.320 Ferrule, Vespel/graphite, 0.5-mm id 0.32-mm capillary columns 5062-3514 (10/pk)
Ferrule, graphite, 0.5-mm id 0.1-mm, 0.2-mm, 0.25-mm, and 0.32-mm
capillary columns
5080-8853 (10/pk)
Column nut, finger-tight (for .100- to
.320-mm columns)
Connect column to inlet or detector 5020-8292
.250 Ferrule, Vespel/graphite, 0.4-mm id 0.1-mm, 0.2-mm, and 0.25-mm capillary
columns
5181-3323 (10/pk)
Ferrule, graphite, 0.5-mm id 0.1-mm, 0.2-mm, 0.25-mm, and 0.32-mm
capillary columns
5080-8853 (10/pk)
Column nut, finger-tight (for .100- to
.320-mm columns)
Connect column to inlet or detector 5020-8292
.100 and .200 Ferrule, Vespel/graphite, 0.37-mm id 0.1-mm and 0.2-mm capillary columns 5062-3516 (10/pk)
Ferrule, Vespel/graphite, 0.4-mm id 0.1-mm, 0.2-mm, and 0.25-mm capillary
columns
5181-3323 (10/pk)
Ferrule, graphite, 0.5-mm id 0.1-mm, 0.2-mm, 0.25-mm, and 0.32-mm
capillary columns
5080-8853 (10/pk)
