8 Maintaining the COC Inlet
Consumables and Parts for the Cool On-Column Inlet
120 Maintaining Your GC
Consumables and Parts for the Cool On-Column
Inlet
See the Agilent catalog for consumables and supplies for a more complete listing, or visit the
Agilent Web site for the latest information (www.agilent.com/chem/supplies).
Table 13 Recommended parts for injections onto 0.53-mm fused silica columns
Column type Part number
Insert, fused silica, 0.53 mm id 19245-20580 (no rings)
Septum nut, 530 µm G1545-80530
Syringe barrel, removable needle, 5 µL 5182-0836
Needle, 530 µm (3/pk) 5182-0832
Plunger button, 10/pk, for manual injections using syringe barrel 5182-0836 5181-8866
On-column insert spring 19245-60760
Table 14 Recommended parts for injections onto 0.53-mm aluminum-clad columns
Column type Part number
Insert, aluminum-clad, 0.53 mm id 19245-20780 (4 rings)
Septum nut, 530 µm G1545-80530
Syringe barrel, removable needle, 5 µL 5182-0836
Needle, 530 µm (3/pk) 5182-0832
Plunger button, 10/pk, for manual injections using syringe barrel 5182-0836 5181-8866
On-column insert spring 19245-60760
Table 15 Recommended parts for injections onto 0.32-mm fused silica columns
Column type Part number
Insert, fused silica, 0.32 mm id 19245-20525 (5 rings)
Septum nut, 250/320 µm 19245-80521
Syringe barrel, removable needle, 5 µL 5182-0836
Needle, 320 µm (3/pk) 5182-0831
Plunger button, 10/pk, for manual injections using syringe barrel 5182-0836 5181-8866
On-column insert spring 19245-60760
