Agilent Technologies 8860 - Exploded Parts View of the Cool On-Column Inlet

8 Maintaining the COC Inlet
Exploded Parts View of the Cool On-Column Inlet
Maintaining Your GC 123
Exploded Parts View of the Cool On-Column Inlet
Figure 11. Cool on-column inlet exploded parts
Septum nut
(0.53 mm)
Septum nut
(0.25-mm and 0.32-mm
columns)
Septum
Spring
Insert
Ferrule
Column nut
Cooling tower assembly
Duckbill septum
