13 Measurements
"Base" on page 176
"Delay" on page 184 Measures between two sources.
Press Settings to specify the
second source.
"Duty Cycle" on page 183 Yes
"Fall Time" on page 183
"Frequency" on page 182 Yes
"Maximum" on page 174 Yes
"Minimum" on page 174 Yes
"Overshoot" on page 176
"Peak-Peak" on page 174 Yes
"Period" on page 181 Yes
"Phase" on page 185 Measures between two sources.
Press Settings to specify the
second source.
"Preshoot" on page 177
"Rise Time" on page 183
"DC RMS" on page 178
"AC RMS" on page 179
"Top" on page 175
"+ Width" on page 183 Yes
"– Width" on page 183 Yes
*
Use the cursors to make other measurements on FFT.
Measurement Valid
for
Math
FFT
*
Valid for
Digital
Channels
Notes
