Utility Settings 19
Agilent InfiniiVision 2000 X-Series Oscilloscopes User's Guide 245
The resultant string is displayed in the "Text =" line above the softkeys.
3 Press the Wait softkey; then, turn the Entry knob to select the number
of minutes to wait before the selected screen saver activates.
When you turn the Entry knob, the number of minutes is displayed on
the Wait softkey. The default time is 180 minutes (3 hours).
4 Press the Preview softkey to preview the screen saver you have selected
with the Saver softkey.
5 To view the normal display after the screen saver has started, press any
key or turn any knob.
To set AutoScale preferences
1 Press [Utility] > Options > Preferences > AutoScale.
2 In the AutoScale Preferences Menu, you can:
• Press the Fast Debug softkey enable/disable this type of autoscale.
When fast debug is enabled, autoscale lets you make quick visual
comparisons to determine whether the signal being probed is a DC
voltage, ground, or an active AC signal.
Channel coupling is maintained to allow easy viewing of oscillating
signals.
• Press the Channels softkey and turn the Entry knob to specify the
channels to be autoscaled:
• All Channels — The next time you press [AutoScale], all channels that
meet the requirements of AutoScale will be displayed.
You can use a connected USB keyboard instead of using the Spell (and other) character
editing softkeys.
