Measurements 13
Agilent InfiniiVision 2000 X-Series Oscilloscopes User's Guide 173
Snapshot All
The Snapshot All measurement type displays a popup containing a
snapshot of all the single waveform measurements.
You can also configure the [Quick Action] key to display the Snapshot All
popup. See "Configuring the [Quick Action] Key" on page 253.
Voltage Measurements
The following figure shows the voltage measurement points.
Measurement units for each input channel can be set to Volts or Amps
using the channel Probe Units softkey. See "To specify the channel units" on
page 60.
Amplitude
Maximum
Minimum
Base
Top
Peak-Peak
