Key Reference 4
N9310A User’s Guide 77
Step Sweep Pressing this softkey reveals a submenu of softkeys to
configure the parameters of a step sweep, including:
• RF/LF start and stop frequencies
• Amplitude start and stop power levels
• Number of point s in a sweep and the dwell time at
each point.
• Key sequence: > Step Sweep
RF Start Pressing this softkey allows you to set the start frequency in
an RF sweep. The allowed frequency range is 9 kHz to 3
GHz, with 0.1 Hz minimum increment. The start frequency
should always be set less than the stop frequency in an RF
sweep.
• Default value: 9.0000 kHz
• Key sequence: > Step Sweep > RF Start
RF Stop Pressing this softkey allows you to set the stop frequency in
an RF sweep. The allowed frequency range is 9 kHz to 3
GHz, with 0.1 Hz minimum increment. The stop frequency
should always be set greater than the start frequency.
• Default value: 3.000 000 0000 GHz
• Key sequence: > Step Sweep > RF Stop
LF Start Pressing this softkey allows you to set the start frequency in
an LF sweep. The allowed frequency range is 20 Hz to 80
kHz, with 0.1 Hz minimum increment. The start frequency
should always be set less than the stop frequency in an LF
swept.
• Default value: 20.0 Hz
• Key sequence: > Step Sweep > LF Start
Sweep
Sweep
Sweep
Sweep
