126
Chapter 13: Using the effects
5. Press the
EFFECT
[F5] key in Mixer mode and select a type of Insert effect. Also, set the other effect
parameters, if necessary.
6. Press the
FX RTN
[F1] key in Assign mode, and select
2 STEREO PAIRS
.
The effect return signals from EFFECT A and B are switched to analog input signals 3/4 and 5/6.
Example: Set the effect return signals to
2 STEREO PAIRS
. In this case, the effect return signals
from EFFECT A are routed as analog inputs 3 and 4.
7. Press the
THRU
[F2] key in Assign mode, and set the corresponding analog inputs to
SOURCE ASSIGN
.
Example: Set the effect return signals from EFFECT A to
SOURCE ASSIGN
.
8. Press the
SOURCE
[F3] key in Assign mode, and assign these analog inputs to tracks.
Example: Assign the effect return signals from EFFECT A to Tracks 5 and 6.
When you turn on the [RECORD SELECT] keys of the recording tracks and start recording,
the sound will be recorded to the tracks with the effect applied.
➸
NOTE :
Make sure that the level of AUX SEND A (when EFFECT A is used) or AUX SEND B (EFFECT
B is used) is set to
0
on the TRACK MIX channels of the corresponding recording tracks. If the level is set
to any value other than
0
, the signals will loop.
