Akai DPS12 User Manual

134
Chapter 13: Using the effects
TRIGGER PAN (I)
This auto pan effect becomes enabled when the output level of AUX SEND A or AUX SEND B exceeds a certain
level. You can also press the MANUAL [F6] key to start the auto pan effect manually.
3
1
B
4
5
Trigger
autopan
Parameter Setting range Function
1 Rate 0.1Hz – 10.0Hz Adjusts the speed of panning.
2 Mode Pan/L>R/R>L Sets the effect of panning. (Refer to AUTO PAN.)
3 Trigger AUX-A/AUX-B/MANUAL Selects signals that enable the auto pan effect (AUX SEND A or AUX
SEND B).
4 Thresh –60dB – 0dB Sets the signal level at which the auto pan becomes effective.
5 Width 0 – 127 Adjusts the panning width.
MONO DELAY (G)
This is a common delay effect.
4
1
3
B
Delay
Pan
Fdback
HFdamp
Parameter Setting range Function
1 Delay 1 – 1500ms Adjusts the delay time.
2 Fdback 0 – 127 Adjusts the amount of delay that is fed back.
3 HFdamp 20Hz – 20kHz Sets a frequency at which the higher range of the feedback sound is cut.
4 Pan L63 – MID – R63 Adjusts the stereo image of the effect sound.
PING PONG DELAY (G)
This delay effect pans the effect sound left and right.
1
3
B
4
Parameter Setting range Function
1 Delay 1 – 1500ms Adjusts the delay time.
2 Fdback 0 – 127 Adjusts the amount of delay that is fed back.
3 HFdamp 20Hz – 20kHz Sets a frequency at which the higher range of the feedback sound is cut.
4 Width 0 – 127 Adjusts the panning width.
