Akai DPS12 - Panning Delay (G); Stereo Delay (G); Xover Delay (G)

135
Chapter 13: Using the effects
PANNING DELAY (G)
This delay effect pans the delay sound left, center, then right (LCR), or right, center, then left (RCL).
4
1
3
B
5
Parameter Setting range Function
1 Delay 1 – 1500ms Adjusts the delay time.
2 Fdback 0 – 127 Adjusts the amount of delay that is fed back.
3 HFdamp 20Hz – 20kHz Sets a frequency at which the higher range of the feedback sound is cut.
4 Mode LCR/RCL Sets the effect of panning.
5 Width 0 – 127 Adjusts the panning width.
STEREO DELAY (G)
This delay effect can be set for the left and right channels individually.
4
1
3
B
5
6
HFdamp
Fdback
HFdamp
Delay
Fdback
Delay
Parameter Setting range Function
1 LDelay 1 – 1500ms Adjusts the delay time of the L channel.
2 Fdback 0 – 127 Adjusts the amount of delay that is fed back (Lch).
3 HFdamp 20Hz – 20kHz Sets a frequency at which the higher range of the feedback sound (Lch) is
cut.
4 RDelay 1 – 1500ms Adjusts the delay time of the R channel.
5 Fdback 0 – 127 Adjusts the amount of delay that is fed back (Rch).
6 HFdamp 20Hz – 20kHz Sets a frequency at which the higher range of the feedback sound (Rch) is
cut.
XOVER DELAY (G)
This is a stereo delay effect that adds width and spread.
4
1
3
B
5
Delay
Delay
Width
Fdback
HFdamp
HFdamp
