63
Chapter 6: Mixer Function
While this screen is displayed, the [F5] key and the [F6] key function as follows:
•
ON/OFF
[F5] key .... switches EQ on/off for the selected channel. To check the on/off status of the selected
channel EQ, select the EQ ON/OFF parameter (see page 62).
•
STRIP
[F6] key........ displays all the EQ parameters for the selected channel. See page 64 for more
information.
Setting the level (EQ HIGH/MID/LOW LEVEL)
The EQ LEVEL parameters determines the level of each range for each channel.
Range: –12dB – 0 – +12dB
■ When TRACK MIX channels are selected ■ When THRU MIX channels are selected
While this screen is displayed, the [F5] key and the [F6] key function as follows:
•
ON/OFF
[F5] key .... switches EQ on/off for the selected channel. To check the on/off status of the selected
channel EQ, select the EQ ON/OFF parameter (see page 62).
•
STRIP
[F6] key........ displays all the EQ parameters for the selected channel. See page 64 for more
information.
➸
NOTE :
When the 2-band EQ is selected, the EQ MID LEVEL parameter does not appear.
Setting the band width (EQ MID WIDTH)
The EQ MID WIDTH parameter determines the band width of the mid-range for each channel.
Range: 0.5 – 16
■ When TRACK MIX channels are selected ■ When THRU MIX channels are selected
While this screen is displayed, the [F5] key and the [F6] key function as follows:
•
ON/OFF
[F5] key .... switches EQ on/off for the selected channel. To check the on/off status of the selected
channel EQ, select the EQ ON/OFF parameter (see page 62).
•
STRIP
[F6] key........ displays all the EQ parameters for the selected channel. See page 64 for more
information.
➸
NOTE :
When the 2-band EQ is selected, the EQ MID WIDTH parameter does not appear.
